GF-KG Clamp-on Flow Sensor
High precision and high stability
Non-invasive measurement
Bi-directional measurement
Fluid volume and detect air bubble
Circuit embedded in the sensor
No blockage, no dead area
Low fluid pressure loss
Nur englische Version
GF-KG ultrasonic clamp-on flow sensors are compact size and can measure flow and output results without external circuitry. The sensors can be directly clamped on flexible plastic tubing to accurately measure the liquid flow rate and detect air bubbles.
The sensors are not in direct contact with the liquid in the tubing and will not contaminate the liquid. They are especially suitable for applications where strict hygiene is required, such as medical devices, bioprocessing, new energy, semiconductors, industrial automation, scientific research, and other fields.
