GF-AM1 Electromagnetic Flow Sensor

The GF-AM1 series is a mini flow meter that integrates a converter and a sensor into one. It is compact and exquisite, with no movable parts and no mechanical wear and tears. The screw connection and installation are very convenient. It is powered by 24VY DC and is available in two options: display screen and no display screen. It features both pulse and communication output.

GF-AM1 can be installed horizontally or vertically. It is recommended that the meter is installed with the electrodes in or close to the horizontal plane to ensure that any passing air or bubbles do not interfere with the measurement. If installed in a vertical pipe, it is highly recommended that flow direction is upwards to guarantee that the pipe remains full at all times. Ensure upstream and downstream straight pipe run requirements are met.
