GP-2000 Pressure Sensor
0kPa~0.35MPa…75MPa
Temperature compensation
316L housing
Small size φ12.6mm
High accuracy and stability
Nur englische Version
Schlagwörter: Flüssigkeit, MEMS, Metallverpackung, mV, Ölgefüllt, Sensor
GP2000 series is a compact and isolated oil-filled pressure sensor, which adopts MEMS silicon chip as the core of pressure sensing, and each sensor is manufactured through strict aging, screening and testing to ensure the excellent quality and high reliability of the product.
Featuring high overload resistance and a wide range of temperatures, these products are widely used in hydraulic systems, loading machinery, pumps, and industrial process control.
