GP-1900 Pressure Sensor

GP-1900 pressure sensor is a MEMS sensing die packaged in a TO-8 structure. The measured pressure is transmitted directly to the silicon die through the pressure port, and the pressure is converted to a voltage signal through a linear relationship. The sensor is temperature-compensated and linearly corrected, it is suitable for use on PCBs or in tight spaces to measure various types of pressure in non-corrosive gases.
